Ultimate performance and scalability
Where high flexibility for medium and large batch production is required, the CNCell is the system of choice. This multi-functional cell is based on standardized modules and it is tailored to customer specifications.
The wide range of available dimensions, production processes, parts handling options and material flow or machine control units allows for a completely customizable set-up of a system tailored to specific needs. All modules perfectly match, so that they can be easily swapped or used together. The equipment can be used almost immediately thanks to the system’s scalable, modular design, which also allows for short planning and implementation times as well as quick adaptation to changes in process and batch size. The CNCell offers superior performance and high-level planning and investment security, and effectively supports the standardization of processes worldwide.
Your Advantages
- High axis speeds allow for short cycle times
- Flexible configuration and diverse possibilities for expansion
- Highly effective through automation option
- Quality control with options to monitor processes
- Wide range of applications
Quick overview
++ = very good + = good (+) = limited − = not recommended
Key features
- Precisely dispensing contours with XYZ axis system
- Modular construction allows for different degrees of automation
- Variable system equipment
- Comprehensive process monitoring and quality control options
- Easy access via safety light curtain or door systems
- User-friendly operation through UViSneo visualization
Typical applications
Typical applications are Pick & Place, Bolting, Joining, Assembly and Labeling such as:
INTEGRATED QUALITY ASSURANCE
Needle measurement & weighing unit modules: Thanks to its modular design, the CNCell can be quickly and easily extended with high-precision sensor technology. Continuous monitoring ensures precise dispensing results.
Needle measurement, based on TCP measurement technology (Tool Center Point), ensures automatic (re-)calibration of the dispensing needle tip. With the aid of two light barriers and zero-point correction, the module guarantees maximum positional accuracy in three dimensions (X, Y and Z axes). Combined with weight control, which checks the specified potting quantities and thus ensures early error detection in the dispensing system, this is an efficient tool for process monitoring.
Comprehensive real-time bead inspection: Our in-line RTVision image processing systems monitor and check bead application at the same time as adhesive and sealant are being applied.
Your benefits:
- Greater productivity for your plant
- Simplified and reliable processes thanks to automation
- Lower error rate leading to savings in material and costs
Video: Accurate dispensing needle measurement
This shows you how needle measurement works: The axis system guides the needle tip to two light barriers. The positions on the X and Y axes are determined when the beam is interrupted. The Z axis is determined by the zero point of the light barriers.
Powerful software
The Universal Visualization UVIS 5 software offers a powerful user interface tailored to the application for all Scheugenpflug cells, vacuum dispensing systems and Scheugenpflug’s ProcessModule. The user always has an overview of the relevant data for all processes as well as associated monitoring, maintenance and analysis tasks.
